2KVA Inverter Generator With Single-cylinder diesel engine EPA Certificated

Basic parameters

Rated frequency	Hz	50 60
Rated power	kVA	1.8
Max. power	kVA	2.0
Rated voltage	V	230 120/240
Rated current	A	7.8 15/7.5
Rated rotation speed	r/min	5000
DC output		12V-5.0A
Power factor	COSΦ	1
Phase number		Single phase

Engine

Engine type	Hz	RG160F
Structure type		Single cylinder,4-stroke, air cooled,overhead valve
Bore×stroke	mm	60×40
Displacement	L	0.113
Compression ratio		9.1:1
Rated power	kW/(r/min)	2.3/5000
Lube oil brand		Above SF SAE 10W-30,15W-40
Lube capacity	L	0.4
Ignition system		T.C.I
Spark plug		CR7HSA
Starting system		Recoil starter
Fuel type		Vehicle lead-free petrol
Lowest fuel consumption	g/KW.h	420

Genset

Fuel consumptiom	g/kW.h	550
Fuel tank capacity	L	4.4
Continuous running time(hr)(rated output)	h	3.3
Noise(unload-full load)	dB(A)/7m	64-69
Overall dimensions	mm	530×290×430
Net weight	kg	23
Structure type		Portable, silent

Dehray Power is committed to providing high quality, high performance, advanced technology engine products and generator set products to the market, as well as comprehensive after-sales technical support and professional technical training. No matter before or after sales, we are trying to provide better service.

From the first demand of the customer, the related engineers would research and analyze on the engine, alternator, control system, product structure, installation and other aspects to provide customers with a variety of power solutions.

Then combined with customer opinions, finalize the customerized solutions to meet customer needs. Our after-sales outlets in various regions to provide customers with convenient localized sales and service support.
